| Main technical parameters of aerial work platforms | |||
| Dimension parameter | Total length | mm | 5998 |
| Total width | mm | 2000 | |
| Total height | mm | 3050/2750/2700 | |
| Quality parameter | Number of passengers (including driver) | 人 | 2+3 |
| Total mass | kg | 3495 | |
| Rated load of the working platform | kg | 120 | |
| Maximum working height | m | 13.5M | |
| Driving parameters | Front overhang | mm | 905 |
| Rear overhang | mm | 1713 | |
| Wheelbase | mm | 3380 | |
| Maximum driving speed | Km/h | 170 | |
| Approach Angle | ° | 25 | |
| Departure Angle | ° | 18 | |
| Parameters of the aerial work platform pickup truck chassis | |
| Chassis | Isuzu JXW1030CSGP two-wheel drive automatic transmission |
| Engine | JE4D25Q6A, 110KW engine, National VI emission standard |
| Cab | Double row seats, capable of accommodating 5 people |
| Temperature regulation | The cab is equipped with air conditioning |
| Partition boards and walkway boards | Stainless steel fences and anti-slip walkway boards |
| Power take-off system | Mechanical operation |
| Work platform | FRP hoist basket dimensions: 600×600×1000mm(length, width, height) (single person, single bucket) |
| Operating line voltage | 0.4 KV |
| Boom form | ★ Hybrid arm |
| Rotary device | 360-degree continuous rotation |
| Outriggers | ★ Front and rear V-shaped herringbone legs, independently adjustable (controllable) |
| Operation | ★ Electric control operation |
| Control system | The CAN bus control system is equipped with a wireless remote control to achieve stepless speed regulation |
| Leveling system | Automatic hydrostatic leveling |
